Phoenix AM provides glass frit perfect for OLED display and lighting.
It has low heat property necessary for closing the OLED element, high laser absorption rate and matching property without thermal stress on glass substrate.Structure of Organic
Light Emitting Diode
LASER
sealing technique
-
-
- ※ Requirements of glass frit
- - Higher laser absorption rate
- - CTE similar to glass substrate
- - Low softening point and matching with filler
Glass Frit product specification
| Product No. |
Glass System | Properties | Firing Process | |||
|---|---|---|---|---|---|---|
| Tg (℃) |
Tp (℃) |
CTE (x10-7/K) |
Density (g/cm3) |
Temp. (℃) |
||
| POS-1F | V2O5-P2O5-BaO | 298 | 460 | 80~100 | 4~5 | Laser |
| POS-184F | V2O5-BaO-TeO2 | 320 | 470 | 80~100 | 4~5 | Laser |
